TOPDRIVE® ROZ1-K - NEW NAME, SAME HIGH QUALITY
Our popular series of double shielded ROZ1-K EMC cables has become part of the TOPDRIVE® series and is now changing its name to TOPDRIVE® ROZ1-K (AS), EMC.
But don't worry, the cable's unique properties and specifications are the same as before.
You can download the data sheets here.
THE BEST SOLUTION FOR FREQUENCY CONVERTERS
The combination of the double shield (foil shield + braided tinned copper shield) makes TOPDRIVE® ROZ1-K (AS), EMC the optimal EMC cable for frequency converters.
TOPDRIVE® ROZ1-K (AS), EMC cables from Scankab Cables are suitable for all applications where double-shielded cables are needed.
The cables are used for industrial and building installations, in public buildings, at power plants as well as for frequency converters and motor installations, or where 0.6 / 1 kV shielded halogen-free cables are required.
See all the specifications here...
All cables in the TOPDRIVE® series are delivered with the highest CPR classes on the market.
ROZ1-K (AS) is delievered with the CPR classification: Cca-s1a,d1,a1
APPLICATION
The cable is specially designed for the connection between the frequency converter and the motor, as well as places where it is necessary to limit the effects of electromagnetic interference (EMI) also known as Radio Frequency Interference (RFI).
The cable is designed with three phase conductors plus 3 symmetrical earth conductors, a halogen-free sheath and flexible class 5 with inner conductors.
BENEFITS & FEATURES
- Electromagnetically protected
- Halogen free
- Chemical & oil resistant
- Water resistant
- CPR class Cca-s1a, d1, a1
- AD3 aspersion
- Low smoke development in case of fire
- Low emission of corrosive gases
- Fire & flame retardant
- Resistant to moisture
- Can be buried and laid in pipes
- For outdoor storage
